0281006059 |
Not in stock
4 bar map sensor with integrated air temp sensor
Distance between mounting holes is : 36 mm
O-ring O.D is : 13 mm
Pin 1 = Signal ground, Pin 2 = NTC, Pin 3 = +5V, Pin 4 = Output signal
Mating connector set: 1J0973704-SET-G. 03K906051. 50-400 kPa. 50 kPa @ 0.5V - 400 kPa @ 4.5 V
27.33 €
34.30 € VAT 25.5%
$ 29.79
4-napainen liitinsarja mm. sensoreihin, sis. kullatut JMT-pinnit + tiivisteet
1J0973704-SET-G
5.96 €
7.48 € VAT 25.5%
$ 6.50
Connector set includes housing, wire seals and terminals.
4 pole connector set, 0.5 - 1.0 mm² (Au), VAG, 1.5 mm gold plated MCP terminals (8K0973704-SET-G)
8K0973704-SET-G
7.36 €
9.24 € VAT 25.5%
$ 8.03
Connector set includes housing, wire seals and terminals.
