Competition Fuel Cell Unit with Integrated 2 L Fuel Surge Tank

• 100% compatible with gasoline, methanol and ethanol(E85).
• Single or Dual in tank pump setup. Hanger for two ∅46mm pumps, comes with inserts for ∅38-39mm pumps.
• Two liter surge tank.
• 24-bolt lid.
• Outlet port, thread AN10 ORB.
• Return port, thread AN8 ORB.
• Venting is done with a rollover vent valve, comes with AN adapter with AN6 male thread (can be changed to AN8 or AN10)
• Fuel filling hole with threaded cap, 38mm inner diameter. Cap can be replaced with 50mm fuel filler neck.
• Electrical connectors for 3 fuel pumps. Two high-pressure pumps + liftpump.
• Compatible with a fuel level sending unit.
• Includes one in tank pipe.

The Nuke Performance CFC Unit eliminates the need for an external surge tank which is other needed when running a fuel cell, it is a perfect use for fuel injected systems. Use with PWM control, combined with the CFC Unit it is an effective solution to prevent emerging heat when running numerous fuel pumps. This is the best way to eliminate fuel starvation that may occur in motorsports. And with the use of the standardized 6x10" 24-bolt fill plate pattern, it fits close to all fuel cells on the market.

Does NOT include fuel pumps or AN fittings, they need to be bought separately.
