HYDR REL BRG, 1400-SERIES, 54MM BRG, 1.84 TALL (TILTON 60-1400)

Tilton’s 1400-Series hydraulic release bearings feature a 54mm (2.13″) radius-face contact diameter bearing for use with flat-finger clutch diaphragm springs. Designed for use with Tilton ST-215 clutches, and suitable for use with many non-Tilton 7.25” & 8.5” clutches, the 1400-Series hydraulic release bearings fit many popular racing transmissions designed to accept 3-bolt pattern “Saab 9000-type” hydraulic release bearings.

  • Superior lightweight aluminum construction
  • Proprietary low-friction surface treatments
  • Unique monoseal technology
  • Wiper-seal debris prevention
  • Smooth and reliable high-quality bearings
  • Constant contact design
  • Self-adjusting

Mount: 3-bolt “Saab 9000-type” pattern
Weight: .85 lbs
Application: 5.5″ – 8.5″ clutches
Overall height: 2.04″ (51.8mm)
Contact: 2.05″ (52mm)
Bearing type: Radius-face
Body and piston material: Billet aluminum
Piston area: 1.215 in2 (784mm2)
Maximum stroke: .700″ (17.8mm)
Ports: AN-3 (3/8″-24)
Included in kit: AN-3 fittings (2)

Typical applications: Fits many popular racing transmissions designed to accept 3-bolt pattern “Saab 9000-type” hydraulic release bearings.

  302.60 € 379.76 € VAT 25.5%
  $ 335.88
