Injectors up to 450 cc / min with 11 mm top diameter

Flow rates and other information can be found in product names. Spray pattern is indicated by a letter: A = thin spray, C = cone spray, E = twin spray. The degree indicates the angle of the spray or the angle between twin sprays.

We also sell, but do not stock, diesel injectors and their spare parts.



The value given for the flow rate in the product name and product code is only for reference.

For actual flow rates of your set, please refer to the flow slip that will accompany your order. The slip will include information for maximum flow and dynamic flow (number and time of impulses).

Flow matching into sets is done at 3 bar pressure and room temperature by measuring both static and dynamic flow.

Some injector providers report the maximum flow in temperatures over 50 C. Because of this, their values for maximum flows are bigger and hence not comparable with ours.

EV14, 12 Ohm, 373cc, E 20°, long spray end, Jetronic, O-O 49 mm, machined 11mm top, 16mm bottom
Product number: 0280158124-11

EV14, 12 Ohm, 373cc, E 20°, long spray end, Jetronic, O-O 49 mm, machined 11mm top, 16mm bottom

  49.21 € 61.76 € VAT 25.5%
  $ 52.66

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14, 12 ohm, 339cc, C20, Jetronic, O-O 49 mm, with long spray end, 11mm machined top (Bosch 0280158038-11)
Product number: 0280158038-11

EV14, 12 ohm, 339cc, C20, Jetronic, O-O 49 mm, with long spray end, 11mm machined top (Bosch 0280158038-11)

  51.68 € 64.86 € VAT 25.5%
  $ 55.30

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14, 12 ohm, 339cc, C20, Jetronic, O-O 54 mm, total 75mm, Hayabusa / Honda adapter and seal, 11mm top adapter (Bosch 0280158038-H11)
Product number: 0280158038-H11

EV14, 12 ohm, 339cc, C20, Jetronic, O-O 54 mm, total 75mm, Hayabusa / Honda adapter and seal, 11mm top adapter (Bosch 0280158038-H11)

  39.79 € 49.94 € VAT 25.5%
  $ 42.58

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14 injector, 12 Ohm, 246 cc, E20°, delta 45°, Jetronic (EV1), O-O 49 mm, Mid, Short 11mm Top Adapter with Filter, Bottom 16 mm (Bosch 0280158226-M11)
Product number: 0280158226-M11

EV14 injector, 12 Ohm, 246 cc, E20°, delta 45°, Jetronic (EV1), O-O 49 mm, Mid, Short 11mm Top Adapter with Filter, Bottom 16 mm (Bosch 0280158226-M11)

  69.42 € 87.12 € VAT 25.5%
  $ 74.28

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14 injector, 12 Ohm, 246 cc, E20°, delta 45°, Jetronic (EV1), O-O 61 mm, Long, Long 11mm Top Adapter with Filter, Bottom 16mm (Bosch 0280158226-L11)
Product number: 0280158226-L11

EV14 injector, 12 Ohm, 246 cc, E20°, delta 45°, Jetronic (EV1), O-O 61 mm, Long, Long 11mm Top Adapter with Filter, Bottom 16mm (Bosch 0280158226-L11)

  69.58 € 87.32 € VAT 25.5%
  $ 74.45

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14 injector, 12 Ohm, 304 cc, E20°, Delta 30°, USCAR, O-O 47 mm, Mid, 11 mm Short Top Adapter, Bottom 16 mm Seal (Bosch 0280158189-M11)
Product number: 0280158189-M11

EV14 injector, 12 Ohm, 304 cc, E20°, Delta 30°, USCAR, O-O 47 mm, Mid, 11 mm Short Top Adapter, Bottom 16 mm Seal (Bosch 0280158189-M11)

  58.67 € 73.63 € VAT 25.5%
  $ 62.78

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14 injector, 12 Ohm, 304 cc, E20°, Delta 30°, USCAR, O-O 61 mm, Long, 11 mm Top Adapter with Filter, Bottom 16 mm Seal (Bosch 0280158189-L11)
Product number: 0280158189-L11

EV14 injector, 12 Ohm, 304 cc, E20°, Delta 30°, USCAR, O-O 61 mm, Long, 11 mm Top Adapter with Filter, Bottom 16 mm Seal (Bosch 0280158189-L11)

  58.83 € 73.83 € VAT 25.5%
  $ 62.95

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14 injector, 12 Ohm, 339cc, C20, Jetronic (EV1), O-O 61 mm, Long, Short 11 mm Top Adapter With Filter, 16 mm Bottom Adapter (Bosch 0280158038-L11)
Product number: 0280158038-L11

EV14 injector, 12 Ohm, 339cc, C20, Jetronic (EV1), O-O 61 mm, Long, Short 11 mm Top Adapter With Filter, 16 mm Bottom Adapter (Bosch 0280158038-L11)

  39.45 € 49.51 € VAT 25.5%
  $ 42.21

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14 injector, 12 ohm, 420 cc, C, USCAR, O-O 49 mm, Mid, Short 11mm Top Adapter with Filter (Bosch 0280158051-M11)
Product number: 0280158051-M11

EV14 injector, 12 ohm, 420 cc, C, USCAR, O-O 49 mm, Mid, Short 11mm Top Adapter with Filter (Bosch 0280158051-M11)

  60.68 € 76.15 € VAT 25.5%
  $ 64.92

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
EV14 injector, 12 ohm, 420 cc, C, USCAR, O-O 61 mm, Long, Long 11mm Top Adapter with Filter, 16mm Bottom (Bosch 0280158051-L11)
Product number: 0280158051-L11

EV14 injector, 12 ohm, 420 cc, C, USCAR, O-O 61 mm, Long, Long 11mm Top Adapter with Filter, 16mm Bottom (Bosch 0280158051-L11)

  60.84 € 76.35 € VAT 25.5%
  $ 65.10

This product is a package, see inside for availability
Product information
Sold in sets flow matched by us. Compatible with standard, race fuels and E85 / RE85.
