Coolant Expansion Tank, 1.0L (NUKE 455-01-201)

Expansion tank capacity 1.0 liter (0.26 gal)
Radiator cap connection 32mm radiator neck, Type-A (not included)
Inlet port thread AN-8 ORB (view assortment)
Outlet port thread AN-10 ORB (view assortment)
Overflow port thread 1/16 NPT (1/16 NPT to 6 mm barb included)
Reservoir design Single-chamber design
Pressure compatibility 0.00–2.50 BAR (0.00–36.25 PSI)
Width (with bracket) 119.0 mm (4.68")
Width (without bracket) 100.0mm (3.94")
Height (to top of cap flange) 170.8mm (6.72")
Depth (with bracket) 119.5mm (4.70")
Weight 498g (1.09lb)
