Sähköinen päävirtakytkin 24 V 500A, BLUE SEA 7703

Control Circuit Connection: Tinned wires
Nominal Voltage: 24V DC
Coil Function: Bi-Stable
Mounting: #10
Amperage Operating Current continuous: 0A
Terminal Stud Torque: 140 in-lb (15.82 Nm)
Continuous Rating: 500A
Intermittent Rating: 700A (5 min)
Cranking Rating 30 sec: 1450A DC
Minimum Operating Temperature: -10° C
Maximum Operating Temperature: 60° C
Cable Size to Meet Ratings: 2x (4/0)
Stud Material: Tinned Copper
Switching Cycles: 100000
Terminal Ring Diameter Clearance: 1.18in (29.97 mm)
Terminal Stud Length: 0.875in (22.23 mm)
Terminal Stud Size: 3/8" - 16 (M10)
